175 Series (1097KW)

12V175 series diesel engine with high pressure, low energy consumption, high reliability, long life characteristics.

  Contact Now
Product Details

Specification of 175 Series

12V175 diesel engine with high pressure, low energy consumption, high reliability, long life characteristics, Through the use of electronic control, high-pressure common rail, Miller cycle, exhaust post-treatment, high-efficiency supercharger, and other new technologies, the engine power performance, economy, reliability, emission index, and other aspects reach the international advanced level: the average effective pressure of diesel engine reaches 2.0MPa, the first overhaul period reaches 35,000 hours, the bare-machine emissions meet GB20891 II.

diesel engine.jpg

DescriptionEngine modelInjection systemSpeed adjustment modeCylinders & ArrangementCylinders Bore,mmPiston Stroke,mm
Engine with fan and radiator12V175PZL-1/0ECU electric monoblock pumpElectronic Speed Governor12 cylinders, V type175190
DescriptionGensets ModelRated power kwRotation speed r/minEngine modelHydraulic transmission coupler/Torque Converter ModelHeight of center
Hydraulic transmission coupling set12V175PZL-1/01097120012V175PZL-1YOZJ750930
