In recent years, with the improvement and promotion of series H16V Genset, The market share of Jichai gas generator sets in the gas power generation market, especially in Shanxi, has been increasing year by year, and the market share of 1000kW low-concentration gas generator sets has reached more than 90%. However, At present, Jichai does not meet the market requirements within the power range of 1000kW~2000kW. It is necessary to develop 190 series gas generator sets covering the power segment of 1000kW~2000kW, so as to maintain the cost advantage over foreign Genset, at the meantime expand the power coverage, continue to improve the competitiveness of 190 series gas generator sets and maintain the competitive advantage.

The single power of the long-stroke 20V190 gas engine covers the power segment of 1000kW~2000kW, and the gas type can take into account natural gas, gas, and biogas, which has a broad market demand prospect.

In recent years, with the improvement and promotion of H16V series gensets, The market share of Jichai gas generator sets in the gas power generation market, especially in Shanxi, has been increasing year by year, and the market share of 1000kW low-concentration gas generator sets has reached more than 90%. However, At present, Jichai does not meet the market requirements within the power range of 1000kW~2000kW. It is necessary to develop 190 series gas generator sets covering the power segment of 1000kW~2000kW, so as to maintain the cost advantage over foreign gensets, expand the power coverage, continue to improve the competitiveness of 190 series gas generator sets and maintain the competitive advantage of providing firewood.

The single power of the long-stroke 20V190 gas engine covers the power segment of 1000kW~2000kW, and the gas type can take into account natural gas, gas and biogas, which has a broad market demand prospect.

Functional description:

1)The container is equipped with a distribution box to provide power to all low-voltage loads in the engine room, such as horizontal radiator fans, control screens, lighting, exhaust (supply) fans (for horizontal distribution), chargers, electric heating (optional), oil pumps, electric heating (optional), and outdoor searchlights. It can also be responsible for controlling related equipment (according to project configuration requirements);

2)Two track suspension beams and a hoist are installed on the top of the engine room, with a lifting capacity of 0.5 tons per beam;

3)Inlet of engine air filter and the engine room are equipped with electric heating devices to avoid freezing and blockage (optional);

4)The floor of the machine room is equipped with an axial drive mechanism for the generator, which enables the generator to detach from the coupling by 200mm. (Optional)

5)If the indoor heating temperature in the machine room is not lower than 5 ℃, an insulation layer needs to be installed under the chassis of the machine room, and electric heating heaters (optional) are used inside the machine room;

6)One explosion-proof acoustic and visual alarm lamp is installed outside each machine room. The lighting inside the machine room is an explosion-proof LED lamp with emergency function. Other equipment and boxes do not need to be explosion-proof (optional).

7)Ladder: Install a simple ladder at a suitable position on the box;

8)Configure the fire protection system in the machine room: Install dry powder fire extinguishers as fire extinguishing devices (standard), and other flame detectors, methane leak detectors, smoke detectors, etc. as optional options;

9)Note: The specific configuration shall be subject to the actual situation of the project.

Application case：

Functional description:

1)The container is equipped with a distribution box to provide power to all low-voltage loads in the engine room, such as horizontal radiator fans, control screens, lighting, exhaust (supply) fans (for horizontal distribution), chargers, electric heating (optional), oil pumps, electric heating (optional), and outdoor searchlights. It can also be responsible for controlling related equipment (according to project configuration requirements);

2)Two track suspension beams and a hoist are installed on the top of the engine room, with a lifting capacity of 0.5 tons per beam;

3)Inlet of engine air filter and the engine room are equipped with electric heating devices to avoid freezing and blockage (optional);

4)The floor of the machine room is equipped with an axial drive mechanism for the generator, which enables the generator to detach from the coupling by 200mm. (Optional)

5)If the indoor heating temperature in the machine room is not lower than 5 ℃, an insulation layer needs to be installed under the chassis of the machine room, and electric heating heaters (optional) are used inside the machine room;

6)One explosion-proof acoustic and visual alarm lamp is installed outside each machine room. The lighting inside the machine room is an explosion-proof LED lamp with emergency function. Other equipment and boxes do not need to be explosion-proof (optional).

7)Ladder: Install a simple ladder at a suitable position on the box;

8)Configure the fire protection system in the machine room: Install dry powder fire extinguishers as fire extinguishing devices (standard), and other flame detectors, methane leak detectors, smoke detectors, etc. as optional options;

9)The machine room requires a silent type, with 85dB at 1m.

10)Note: The specific configuration shall be subject to the actual situation of the project.

Application case：

In cooperation with the WOODWARD Company of the United States, A kind of pre-supercharger hybrid gas engine has been developed by using the internationally advanced external gas mixing method, advanced electronic control technology, and rarefied combustion control strategy, with high-cost performance and good control and reliability. This series of products have been sold well at home and abroad since they were put on the market in 2005, and have achieved good benefits for customers.

Series 140 engine is a high-performance, high-speed engine with full intellectual property rights developed by Jichai and AVL, featuring high pressurization, low energy consumption, high reliability, and long service life. It can meet the TIER2 and European Ⅲ emission standards,　Widely used in oil vehicle drilling rigs, oil specials, wellsite generator sets, mobile power stations or backup power sources, construction machinery, trucks, and other fields. Each technical index achieves the international advanced level, the domestic leading level of 5-10 years.

On the basis of Z12V190B diesel engine, series 2000 diesel engines have been greatly improved in terms of improving the reliability, economy, power performance, appearance quality and convenience for maintenance of diesel engines, so as to better meet the requirements of power for various oil drilling rigs, generator sets and construction machinery.

Series 26/32engines include V-12, 16, 18 cylinders, and in-line 6, 8, and 9 cylinder serials. The design is based on 12V/2632 diesel engines, whose fuel involves diesel, heavy oil, and natural gas. It is a highly pressurized engine with full intellectual property rights developed by Jichai and AVL Of Austria. It is a series of medium-speed engines with high pressurization, great success, low fuel consumption, high reliability, and long life, which is developed by Jichai and AVL of Austria which Jichai has 100% intellectual property rights. It uses the world's leading high-pressure common rail fuel system, greatly reducing camshaft size, dual electronic control system, high supercharging technology, ultra supercharging technology, MPC exhaust system. Strong Miler cycle, double stage intermediate cooling technology. Self-cleaning filtration technology greatly improves engine performance and emissions.

Series 26/32 heavy oil machine is a new product developed by Jichai to meet the needs of China's economic and environmental development. The key technical indexes of 26/32 series heavy oil engines, such as average pressure/fuel consumption rate, power, and emission, have reached or exceeded the international advanced level. As it burns heavy oil, it greatly reduces the running cost of the engine and has the characteristics of high reliability, low emission and high intelligence. It is well received by users of power equipment such as inland river shipping, dredging project, offshore oil equipment manufacturing, Chinese port construction, and large-scale power station.

so as to better meet the power requirements of various oil drilling rigs, generator sets and construction machinery.2000 series diesel engine can be matched with torque converter engine set, Hydraulic transmission coupling set and diesel generator set, used for driving drilling rigs or mud pumps, and can also be matched with fire pump, flood pump, etc.

Series 6000 diesel engines is developed by Jichai incorporate with Austria AVL company and domestic well-known colleges and universities, research institutes cooperation, by means of the latest development of internal combustion engine, through the computer-aided design, simulation, finite element analysis research of engine combustion process, such as crankshaft torsional vibration, turbocharger matching, into the exhaust system on the basis of the simulation, optimization of design and development6000 series land diesel engine is a cooperation between Jichai and AVL of Austria as well as famous universities and research institutes in China，use the latest development methods for the internal combustion engine, designed and developed through computer-aided design, simulation calculation, finite element analysis and research on the engine combustion process, crankshaft torsional vibration, supercharger matching, intake, and exhaust system. The advanced technology and mature spare parts of the international high-power internal combustion engine industry are adopted, so that the engine has made great progress in increasing the average effective pressure, reducing fuel consumption and emission, and improving the reliability and safety while expanding the power of the original 190 series diesel engine. Widely used in oil drilling, Marine power, offshore drilling platform, power generation, and other fields.

On the basis of the Z12V190B diesel engine, the 2000 series diesel engine has been greatly improved in terms of reliability, economic and power performance, appearance quality, maintenance, etc., so as to better meet the power requirements of various oil drilling rigs, generator sets, and construction machinery. It has been used in many electric drill projects.

12V175 diesel engine has the characteristics of high supercharging, low energy consumption, high reliability, and long life，Its dynamic performance, economy, reliability, and emission index have reached the international advanced level through the use of electronic control, high-pressure common rail, Miller cycle, exhaust after-treatment, high-efficiency supercharger and other new technologies. The average effective pressure of diesel engine reaches 2.0mpa, the first overhaul period reaches 35,000 hours, and the bare engine emission meets GB20891 II. 12V175 diesel generator set is a high-performance power set developed for the working condition of an electric drilling machine. According to the characteristics of oilfield working conditions, the Genset been designed in such aspects as starting performance, sudden reduction capacity, and continuous working capacity: In order to realize unattended, the Genset installed a remote monitoring system, which realized the real-time recording of the Genset field data and remote monitoring on the Internet.

The power range of China's gas engine is mainly from 200kW to 600kW, and the market demand for gas engines above 1000kW is very big. Series 6000 gas engine is a high-power gas engine developed by our company for this situation. Now the series of gas engine power can be up to 1600 kw. It adopts the most advanced technology of air-fuel ratio control, engine performance, fuel economy, reliability and security were greatly improved, and its main performance index has reached the international advanced level, can form a complete set of gas generator and compressor sets, meet the needs of urban and wellsite power supply and compressor markets.

12V175 diesel generator set is a high-performance power set developed for the working condition of an electric drilling machine. According to the characteristics of oilfield working conditions, the Genset has been designed in terms of starting performance, sudden reduction capacity, and continuous working capacity. In order to realize unattended operation, Genset has installed a remote monitoring system, which realizes the real-time recording of the Genset field data and remote monitoring on the Internet.

Jichai series 140 engine is a high-performance, high-speed engine developed by Jichai in cooperation with AVL with all intellectual property rights，It has the feature of high pressure, low energy consumption, high reliability, long - life, meets the TIER2 and European Ⅲ emission standards，it is widely used in oil vehicle drilling rigs, oil specials, wellsite generator sets, mobile power stations or backup power sources, construction machinery, trucks and other fields. Each technical index achieves the international advanced level, the domestic leading level of 5-10 years.

The power range of China's gas engine is mainly from 200kW to 600kW, and the market demand for gas engines above 1000kW is very big.6000 series gas engine is a high-power gas engine developed by our company for this situation. Now this series of gas engine power can be up to 1600 kw. It adopts the most advanced technology of air-fuel ratio control, engine performance, fuel economy, reliability, and security were greatly improved, and its main performance index has reached the international advanced level, can form a complete set of gas generator and compressor set, meet the demand of the city, well-site power supply and compressor.

Series 6000 land-used diesel engine is developed by Jichai with Austria AVL company and domestic well-known colleges and universities, research institutes, and by means of the latest development of internal combustion engine, through the computer-aided design, simulation, finite element analysis and research on the combustion process, the crankshaft torsional vibration of engine and turbocharger matching, into the exhaust system on the basis of the simulation, optimization of design and development. The advanced technology and mature parts and components of the current international high-power internal combustion engine industry are adopted, so that the engine can not only expand the power of the original 190 series diesel engine, but also make great progress in improving the average effective pressure, reducing fuel consumption and emission, and improving the reliability and safety of use.

According to order No. 17 of the Ministry of Petroleum Industry (82), Jichai started the research and development of a high-power turbocharged natural gas engine in 1982. From 1984 to 1988, three prototype tests were carried out in the laboratory and 10,000 hours of industrial tests were carried out in Shengli Oilfield. It passed the national appraisal on October 12, 1988, and the type of the appraisal machine is 600kW/ 1000R /min externally mixed supercharged high-power gas engine. After years of continuous improvement, the products have been serialized and widely used in various oil fields and gas applications, which have brought great economic benefits.

12V175 diesel engine has the characteristics of high supercharging, low energy consumption, high reliability, and long life，through the use of electronic control, high-pressure common rail, Miller cycle, exhaust after-treatment, high-efficiency supercharger, and other new technologies，Its dynamic performance, economy, reliability, and emission index have reached the international advanced level: The average effective pressure of diesel engine reaches 2.0mpa, the first overhaul period reaches 35,000 hours, and the bare engine emission meets GB20891 II.12V175 diesel-oil generator set is a kind of high-performance power set developed for the working condition of electric drilling machine. According to the characteristics of oilfield working conditions, the engine has been designed in terms of starting performance, sudden reduction capacity, and continuous working capacity. In order to realize unattended operation, the engine has installed a remote monitoring system, which realizes the real-time recording of the engine's field data and remote monitoring on the Internet.

Series 26/32 engine is developed by Jichai in cooperation with AVL Of Austria which Jigai has all intellectual property rights of high pressurization, high power, low fuel consumption, high reliability, and long life of medium-speed engines. All the technical indexes have reached the international advanced level。 It uses the world's leading high-pressure common rail fuel system, greatly reducing camshaft size, dual electronic control system, high supercharging technology super high supercharging technology, MPC exhaust system. Strong Miler cycle, double stage intermediate cooling technology. Self-cleaning filtration technology greatly improves engine performance and emissions.

Series 26/32 heavy oil machine is a new product developed by Jichai to meet the needs of China's economic and environmental development and Jichai owns all independent intellectual property rights. The key technical indexes of series 26/32 heavy oil engines, such as average pressure, fuel consumption rate, single-cylinder power, and emission, have all reached or exceeded the international advanced level. Because it burns heavy oil, it greatly reduces the running cost of the engine and has high reliability, low emission, and high intelligence, and other characteristics. It is well received by users of power equipment such as inland river navigation, dredging project, offshore oil equipment manufacturing, Chinese port construction, and large-scale power station.

On the basis of Z12V190B diesel engine, the 2000 series diesel engine has been greatly improved in terms of improving the reliability, economic performance, and power performance of diesel engine, solving three leaks, appearance quality, and maintenance, etc., so as to better meet the power requirements of various oil drilling rigs, generator sets, and construction machinery. Series 2000 diesel engines can be matched with torque converter sets, coupler sets, and diesel generator sets for driving drilling rigs or mud pumps, as well as fire pumps and flood pumps, etc.

HSEE emergency power supply system is a product designed and developed by Jichai for the purpose of providing high-quality power equipment in the field of oil sales by implementing the HSE policy of CNPC and combining with the requirements of "internationalized concept, standardized design, unified image and maximum efficiency" of the design and construction of refueling (gas) stations and oil depot.

HSEE emergency power supply system solves the power failure event in the sudden situation of the gas station and oil depot and ensures the normal operation of the gas station and oil depot.

Meet the demand of power supply capacity in the special environment of gas stations and oil depots; After the power is cut off, quickly restore the power supply to the gas station; The power supply system has advantages in safety, economy, and noise, etc.

This series of products are mainly used in the oil sales field of refueling (gas) stations, oil depot, and so on, as an emergency standby power supply. It can also be used in hotels, hospitals, and other civilian areas.

Series 6000 diesel engine is developed by Jichai with Austria AVL company and domestic well-known colleges and universities, research institutes, by using the latest development means of internal combustion engine and adopting the advanced technology and mature spare parts of the current international high-power internal combustion engine industry, The engine has made great progress in increasing average effective pressure, reducing fuel consumption and improving reliability and safety while expanding the power of the original 190 series diesel engine. Widely used in oil drilling, Marine power, offshore drilling platform, power generation, and other fields.

140 cylinder series engine is a kind of high-speed engine with the character of high pressure, low energy consumption, high reliability, long life, the technical indicators reached the international advanced level, leading the domestic level of 5-10 years, Jichai has 100% intellectual property rights.，

The engine adopts modular design, high-pressure common rail, high pressure, closed breathing system, and other advanced international internal combustion engine technology, meet the low emission standards, widely used in ship projects.
